| SPECIFICATIONS:
Holding Torque....... 315 oz-in
Rotor Inertia.......... 6.72 oz-in2
Step Angle............... 1.8 deg.
Weight....................... 5.4 lbs
|
Parallel |
Series |
Half Coil |
| Resistance |
.25 ohms |
1.0 ohms |
.50 ohms |
| Rated Current |
7.0 Amps |
3.5 Amps |
5.0 Amps |
| Rated Voltage |
1.77 volts |
3.5 volts |
2.5 volts |
| Inductance |
2.9 mH |
11.6 mH |
2.9 mH |
|
MOTOR POWER CONNECTORS:
|
|
|
4 pin female circular connector-front view
cable length-10' standard
|
|
