| SPECIFICATIONS:
Holding Torque....... 112 oz-in
Rotor Inertia.......... 1.14 oz-in2
Step Angle............... 1.8 deg.
Weight....................... 2.0 lbs
|
Parallel |
Series |
Half Coil |
| Resistance |
1.2 ohms |
4.6 ohms |
2.3 ohms |
| Rated Current |
3.6 Amps |
1.26 Amps |
1.78 Amps |
| Rated Voltage |
2.94 volts |
2.97 volts |
4.2 volts |
| Inductance |
4.7 mH |
18.8 mH |
4.7 mH |
|
MOTOR POWER CONNECTORS:
|
|
|
| 5 pin female DIN connector-front
view |
4 pin female circular connector-front view
cable length-10' standard |
|
