SPECIFICATIONS:
Holding Torque....... 350 oz-in
Rotor Inertia.......... 4.59 oz-in2
Step Angle............... 1.8 deg
Weight.................... 2.5 lbs
| Resistance |
0.28 ohms
|
| Rated Current |
6.6 Amps
|
| Rated Voltage |
1.85 volts
|
| Inductance |
1.54 mH
|
|
MOTOR POWER CONNECTORS:
|
|
|
4 pin female circular connector-front view
cable length-10' standard
|
|
